High-Efficiency SJ65/33 HDPE Single Wall Corrugated Pipe Extrusion Machine

The SJ65/33 HDPE Single-Wall Corrugated Pipe Production Line is a high-efficiency automated system designed for manufacturing high-density polyethylene (HDPE) single-wall corrugated pipes with a diameter range of 12-50mm.

Utilizing advanced extrusion molding technology, this equipment produces lightweight, flexible, and corrosion-resistant corrugated pipes, widely used in agricultural irrigation, cable protection, ventilation ducts, and more.

• High Efficiency & Stable Production
  • Equipped with an SJ65 single-screw extruder (screw diameter: 65mm, L/D ratio: 33:1), ensuring uniform plasticization and stable output
  • Modular molding system allows quick mold changes to accommodate different pipe diameters (12/16/20/25/32/40/50mm)
• High-Quality Pipe Output
  • Single-wall corrugated structure provides lightweight yet rigid pipes with excellent pressure resistance, facilitating easy transportation and installation
  • Superior chemical and UV resistance, suitable for outdoor and underground applications
• Intelligent Control System
  • PLC-based automation monitors extrusion temperature, forming speed, and cooling efficiency in real time for consistent production quality
  • User-friendly HMI touchscreen interface with fault diagnostics and production data logging
• Energy-Efficient & Eco-Friendly
  • Optimized heating and cooling systems reduce energy consumption and operational costs
  • Low-noise operation complies with environmental standards
